Hull Type: | Fin w/spade rudder | Rig Type: | Masthead Sloop | ||
LOA: | 35.08' / 10.69m | LWL: | 28.75' / 8.76m | ||
Beam: | 11.00' / 3.35m | Listed SA: | 607 ft2 / 56.39 m2 | ||
Draft (max.) | 6.00' / 1.83m | Draft (min.) | |||
Disp. | 13000 lbs./ 5897 kgs. | Ballast: | 5200 lbs. / 2359 kgs. | ||
SA/Disp.: | 17.63 | Bal./Disp.: | 40.00% | Disp./Len.: | 244.22 |
Designer: | C. William Lapworth | ||||
Builder: | Jensen Marine (USA) | ||||
Construct.: | FG | Bal. type: | |||
First Built: | 1980 | Last Built: | # Built: | ||
AUXILIARY POWER (orig. equip.) | |||||
Make: | Universal | Model: | |||
Type: | Diesel | HP: | |||
RIG DIMENSIONS KEY | |||||
I: | 46.50' / 14.17m | J: | 15.50' / 4.72m | ||
P: | 39.50' / 12.04m | E: | 12.50' / 3.81m | ||
PY: | EY: | ||||
SPL: | ISP: | ||||
SA(Fore.): | 360.38 ft2 / 33.48 m2 | SA(Main): | 246.88 ft2 / 22.93 m2 | ||
Total(calc.)SA: | 607.25 ft2 / 56.41 m2 | DL ratio: | 244.22 | ||
SA/Disp: | 17.64 | Est. Forestay Len.: | 49.02' / 14.94m |
